• (4) color-keyed coat hooks
• (4) load floor tie-down hooks
• 12V pwr points -inc: (2) front, (1) second row
• 4-line message center w/outside temp display & compass
• 60/40 split-folding 2nd row seat w/recline
• AM/FM stereo w/CD/MP3 player -inc: audio input jack
• Cargo area center dome lamp
• Cargo management system
• Cargo shade (not included with 3rd row)
• Center dome lamp w/1st & 2nd row map lights
• Color-keyed cloth sunvisors -inc: illum visor vanity mirrors
• Color-keyed leather-wrapped tilt steering wheel w/audio & climate controls
• Cruise control
• Electrochromic rearview mirror w/microphone
• Front/rear color-keyed carpeted floor mats
• Grab handles -inc: (1) at passenger seat, (2) in 2nd row
• Illuminated entry
• Illuminated glove box
• Leather heated low back front sport bucket seats -inc: 10-way pwr driver seat, pwr driver lumbar & recline, manual passenger lumbar & recline, 2-way adjustable head restraints
• Manual 3rd row seat
• Manual climate control w/CFC-free rotary controls
• Mid series floor console w/floor shift handle
• Overhead console
• Pwr door locks
• Pwr windows w/1-touch driver down
• Rear window defogger
• SecuriCode remote keyless entry w/keypad
• SecuriLock passive anti-theft system
• SIRIUS satellite radio (subscription required)
• SYNC voice-activated communications & entertainment system -inc: Bluetooth® capability, steering wheel audio controls, USB port, audio input jack, 911 assist, vehicle health report, turn-by-turn navigation, real-time traffic *Traffic reports, GPS turn by turn navigation & information services subject to late availability*
• Trip computer -inc: warning lights, cruise control "on" indicator
• Whip style fender-mounted antenna

• 1-touch integrated start ignition switch
• 130-amp alternator
• 3.55 axle ratio
• 72 amp/hr maintenance-free battery -inc: battery saver feature
• Class II trailer tow prep pkg w/4-pin wire harness
• Frame hider
• Independent front/rear suspension
• Pwr 4-wheel anti-lock disc brakes
• Pwr rack & pinion steering
• Rear wheel drive
• Trailer sway control

• 2nd generation dual front airbags
• 2nd generation dual front side seat airbags
• Adaptive energy-absorbing steering column
• AdvanceTrac w/Roll Stability Control (RSC)
• Belt-Minder feature
• Child safety rear door locks
• Front passenger sensing system
• LATCH system on rear outboard seat locations
• Safety canopy air curtain system -inc: head protection of outboard passengers in the front two rows
• Seat belts -inc: pretensioners, energy management system, adjustable height in 1st row
• SOS Post Crash Alert System
• Tire pressure monitoring system

4.0L SOHC 12-VALVE V6 ENGINE

• (STD)

• Rear Wheel Drive
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Tires - Front All-Season
• Tires - Rear All-Season
• Aluminum Wheels
• Conventional Spare Tire
• Luggage Rack
• Running Boards/Side Steps
• Automatic Headlights
• Fog Lamps
• Power Mirror(s)
• Privacy Glass
• Intermittent Wipers
• Variable Speed Intermittent Wipers
• AM/FM Stereo
• CD Player
• MP3 Capability
• Auxiliary Audio Input
• MP3 Capability
• Steering Wheel Audio Controls
• Bluetooth® Connection
• Telematics
• Auxiliary Audio Input
• Navigation from Telematics
• Requires Subscription
• Satellite Radio
• Requires Subscription
• Power Driver Seat
• Leather Seats
• Bucket Seats
• Heated Front Seat(s)
• Driver Adjustable Lumbar
• Passenger Adjustable Lumbar
• Pass-Through Rear Seat
• Rear Bench Seat
• 3rd Row Seat
• Floor Mats
• Adjustable Steering Wheel
• Steering Wheel Audio Controls
• Leather Steering Wheel
• Cruise Control
• Trip Computer
• Power Windows
• Power Door Locks
• Keyless Entry
• Power Door Locks
• Cruise Control
• Immobilizer
• A/C
• Rear Defrost
• Auto-Dimming Rearview Mirror
• Driver Vanity Mirror
• Passenger Vanity Mirror
• Driver Illuminated Vanity Mirror
• Passenger Illuminated Visor Mirror
• Power Outlet
• Front Reading Lamps
• Rear Reading Lamps
• Cargo Shade
• Traction Control
• Stability Control
• Driver Air Bag
• Passenger Air Bag
• Front Side Air Bag
• Passenger Air Bag Sensor
• Front Head Air Bag
• Rear Head Air Bag
• Child Safety Locks
• Tire Pressure Monitor

• Brakes
• Brake ABS System: 4-Wheel
• Brake Type: Pwr
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.01 x 0.43
• Rear Brake Rotor Diam x Thickness (in): 11.85 x 0.39
• Cargo Area Dimensions
• Cargo Area Length : Floor to Console (in)
• Cargo Area Length : Floor to Seat 1 (in)
• Cargo Area Length : Floor to Seat 2 (in)
• Cargo Area Length : Floor to Seat 3 (in)
• Cargo Area Length : Floor to Seat 4 (in)
• Cargo Area Width : Beltline (in)
• Cargo Box Width : Wheelhousings (in)
• Cargo Volume to Seat 1 (ft³): 83.7
• Cargo Volume to Seat 2 (ft³): 43.9
• Cargo Volume to Seat 3 (ft³): 13.6
• Cooling System
• Total Cooling System Capacity (qts): 7.8
• Electrical
• Cold Cranking Amps : 0° F (2nd)
• Cold Cranking Amps : 0° F (Primary)
• Maximum Alternator Capacity (amps): 130
• Maximum Alternator Watts: 1950
• Emissions
• EPA Greenhouse Gas Score: 10.8
• Tons/yr of CO2 Emissions : 15K mi/year
• Exterior Dimensions
• Ground Clearance, Front (in): 8.3
• Ground Clearance, Rear (in): 8.3
• Ground to Top of Load Floor (in): 31.4
• Height, Overall (in): 71.9
• Length, Overall w/rear bumper (in): 193.4
• Overhang, Front (in): 35.4
• Overhang, Rear w/bumper (in): 44.3
• Rear Door Opening Height (in): 32.9
• Rear Door Opening Width (in): 48.3
• Wheelbase (in): 113.7
• Width, Max w/o mirrors (in): 73.7
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 22.5
• Fuel Tank Location: Midship
• Interior Dimensions
• Front Head Room (in): 39.8
• Front Hip Room (in): 55.4
• Front Leg Room (in): 42.4
• Front Shoulder Room (in): 59.0
• Passenger Capacity: 7
• Second Head Room (in): 38.7
• Second Hip Room (in): 55.5
• Second Leg Room (in): 36.9
• Second Shoulder Room (in): 58.9
• Third Head Room (in): 37.4
• Third Hip Room (in): 45.3
• Third Leg Room (in): 34.9
• Third Shoulder Room (in): 53.1
• Mileage
• EPA Fuel Economy Est - City (MPG): 14
• EPA Fuel Economy Est - Hwy (MPG): 20
• Fuel Economy Est-Combined (MPG): 17
• Steering
• Steering Ratio (:1), On Center: 18.9
• Steering Type: Power Rack & Pinion
• Turning Diameter - Curb to Curb (ft): 36.8
• Turning Diameter - Wall to Wall (ft): 38.4
• Summary
• Body Style: 4 Door
• Vehicle Name: Ford Explorer
• Suspension
• Axle Capacity - Front (lbs): 3240
• Axle Capacity - Rear (lbs): 3600
• Axle Ratio (:1) - Rear: 3.55
• Axle Type - Front: Upper SLA
• Axle Type - Rear: IRS
• Shock Absorber Diameter - Front (mm): 32.0
• Shock Absorber Diameter - Rear (mm): 32.0
• Spring Capacity - Front (lbs): 2470
• Spring Capacity - Rear (lbs): 2200
• Stabilizer Bar Diameter - Front (in): 1.34
• Stabilizer Bar Diameter - Rear (in): 0.77
• Suspension Type - Front: Independent SLA
• Suspension Type - Rear: Independent SLA
• Tires
• Front Tire Capacity (lbs): 1700
• Front Tire Order Code: TC2
• Front Tire Size: P245/65R17
• Rear Tire Capacity (lbs): 1700
• Rear Tire Order Code: TC2
• Rear Tire Size: P245/65R17
• Revolutions/Mile : 45 mph - Front
• Revolutions/Mile : 45 mph - Rear
• Revolutions/Mile : 45 mph - Spare
• Spare Tire Capacity (lbs): 1700
• Spare Tire Size: P245/65R17
• Trailering
• Dead Weight Hitch - Max Tongue Wt. (lbs): 350
• Dead Weight Hitch - Max Trailer Wt. (lbs): 3500
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 525
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 3500
• Vehicle
• Rear Door Type: Liftgate
• Weight Information
• Curb Weight - Front (lbs): 2338
• Curb Weight - Rear (lbs): 2117
• Gross Axle Wt Rating - Front (lbs): 2860
• Gross Axle Wt Rating - Rear (lbs): 3340
• Gross Combined Wt Rating (lbs): 8500
• Gross Vehicle Weight Rating Cap (lbs): 6010
• Wheels
• Front Wheel Material: Aluminum
• Front Wheel Size (in): 17 x 7.5
• Rear Wheel Material: Aluminum
• Rear Wheel Size (in): 17 x 7.5
• Spare Wheel Material: Steel
• Spare Wheel Size (in): 17 x 7.5
